Rev: 09.15.20 Page 7 CCD-0001531
Manual Override
The Level-Up LCD 5th Wheel Leveling system can be manually operated with an electric drill. In the event of
electrical or system failure, this manual override method of extending and retracting the jacks can be used.
Note: Unhook the hydraulic power unit motor from the main power source (battery or shore power) prior
to attempting the manual override procedure.
1. Locate the valves that are paired with the landing gear or leveling jack to be manually overridden.
A. Landing Gear - Valve located on the lead landing gear (Fig. 2).
2. Using a 5/32” hex wrench, open the valve by turning the manual override set screw clockwise (Fig. 3).
3. Remove protective label (Fig. 4A) from power unit motor revealing manual override coupler.
4. Using an electric drill with a
¼”
hex bit, insert the hex bit into the manual override coupler (Fig. 5) to
manually operate the system.
A. Run the drill forward (clockwise) (Fig. 5A) to retract the landing gear or leveling jacks.
B. Run the drill in reverse (counterclockwise) (Fig. 5B) to extend the landing gear or leveling jacks.
5. Make sure to turn the manual override set screw on the valve back to the counterclockwise position
after extending or retracting the landing gear or leveling jacks.
Error Codes
LCD Message What's Happening? What Should Be Done?
"EXCESS ANGLE"
Controller not properly secured.
Check and secure controller placement.
Excessive angle reached during auto operation.
Relocate the 5th Wheel.
"EXCESSIVE ANGLE"
Controller not properly secured.
Check and secure controller placement.
Excessive angle reached during manual operation.
Relocate the 5th Wheel.
"FEATURE DISABLED"
Front of 5th Wheel below level when starting auto-level
process (only when trying to initiate Hitch Recognition).
Push the FRONT Button to raise the 5th Wheel up to hitch
height and connect to tow vehicle.
Touchpad power not cycled between consecutive
leveling operations.
Turn touchpad off and then back on to reset the system.
Zero Point not set.
Set Zero Point.
"LOW VOLTAGE"
Battery voltage dropped below 9.5V.
Check wiring - repair or replace.
Test battery voltage under load - charge or replace.
"OUT OF STROKE"
Jack has reached maximum stroke length and is
unable to lift.
Check disposition of jacks and/or relocate the 5th Wheel.
"EXTERNAL SENSOR"
Bad connection or wiring from the controller to
the sensor.
Replace or repair connection to rear remote sensor.
"JACK TIME OUT"
Time limit exceeded for the requested auto operation.
Check disposition of jacks.
"AUTO LEVEL FAIL"
Unable to auto-level due uneven ground.
Check disposition of jacks and/or relocate the 5th Wheel.
Unable to auto-level due to Zero Point being
set incorrectly.
Reset zero point.
"BAD CALIBRATION"
Sensor calibration values are out of range.
Replace controller.
"INTERNAL SENSOR"
Internal sensor problem.
Replace controller.
**PANIC STOP**
"FUNCTION ABORTED"
The User pressed a button on the touchpad during an
automatic operation.
Restart automatic operation and then refrain from
pressing any buttons on the touchpad.
