Lippert Unity X4 User Manual

Rev: 05.06.23 Page 20 CCD-0007005
17. EXTEND AND RETRACT INPUTS (Fig. 57): Scroll down to the EXTEND AND RETRACT INPUTS.
18. Select the input numbers to be assigned to EXTEND and RETRACT for this output (Fig. 58).
19. Press SET (Fig. 58A) Saved! will replace Loaded! on the screen (Fig. 59A)
Fig. 57 Fig. 58
A
A
Fig. 59

Lippert Unity X4 Specifications

General

Brand	Lippert
Model	Unity X4
Category	Control Unit
Language	English
