Lite-on Tech TR101 - Connecting Power Supply Cables

TR101 Motherboard
10
Connect the Power Supply Cables
NOTE: The ATX power connector is keyed for proper insertion.
1. Place the plastic clip of the power connector over the plastic tab on the motherboard power connector.
The plastic clip should lock into the plastic tab.
Power Supply Connector
