TR101 Motherboard
22
Peripheral Setup
The items listed in the Peripheral Setup Menu may include no or more than one setup items. Use the arrow
keys to nav
igat
e through the m
enu and use the <
PgUp> or
<PgDn>
keys to select
the desir
ed opti
on f
or each
item.
AMIBIOS SETUP – PERIPHERAL SETUP
©2001 AMERICAN MEGATRENDS, INC. ALL RIGHTS RESERVED
OnBoard IDE Both Available Options:
OnBoard AC’97 Audio Enabled
OnBoard FDC Auto
OnBoard Serial PortA Auto
OnBoard Serial PortB Auto
Serial PortB Mode Normal
IR Duplex Mode Half Duplex
IR Receiver Polarity Active Low
IR Xmitter Polarity Active Low
OnBoard Parallel Port Auto
Parallel Port Mode ECP
Parallel Port IRQ Auto
Parallel Port DMA Channel Auto
ESC: Exit
KL
: Sel
PgUp/PgDn: Modify
F1: Help F2/F3: Color
