TR101 Motherboard
1
Chapter 1 Introduction
Motherboard Specifications
Form Factor:
•
Micro ATX Form Factor
•
Size 9.0” x 8.4”, Four Layer Board
Processor
:
•
Support Intel Celeron
®
/ Pentium III

/ Tualatin
®
.
•
Intel Socket-370 mechanism for universal motherboard.
•
66/100/133MHz Front Side Bus frequency.
Cache Memory:
•
Processor integrated on-die 32KB level-one (L1) and 128KB/256KB level-two (L2) cache.
System Memory:
•
2 DIMM Sockets support up to 512MB memory capacity.
•
Support PC100 SDRAM DIMM module.
•
Un-buffered, Non-ECC DIMM only.
Core Logic Chipset:
•
Intel 810E GMCH (Graphics and Memory Controller Hub).
•
ICHX (I/O Controller Hub).
PCI bus:
•
PCI 2.2 compliant.
•
PME# and 3.3V Aux signals to support power management.
Audio/Modem:
•
AC’97 interface in ICHX.
•
AC’97 CODEC ADI AD1885.
•
Compliant with AC’97 revision 2.1 specification.
•
3 Audio jacks (Line out, Line In, Mic In).
•
3 Audio headers (CD In, Modem In, Aux In).
•
Front audio headers (Line In, Mic In)
