TR101 Motherboard
2
On Board EIDE:
•
2 Bus Master IDE Ports (Up to 4 IDE devices). Support Ultra DMA 33/66 MB/sec integrated in
ICHX.
On Board I/O:
•
LPC revision 1.0 super I/O controller Winbond W83627HF.
•
1 Floppy connector.
•
Stacked PS/2 keyboard & mouse connector.
•
4 USB ports, Dual stacked ports at back and 2 at front header (W81181D Option).
•
1 Parallel port (ECP/EPP).
•
1 Serial port.
•
1 Serial port header.
•
Hardware monitor capability by Winbond W83627HF (Option).
•
3 Fan headers.
Integrated Graphics:
•
Integrated full 2D/3D/DirectX acceleration. (AGP 2X Mode).
•
Integrated 230MHz RAMDAC and hardware motion compensation (30 frame/sec).
•
Desktop display modes up to 1600x1200x8bit @ 85Hz.
•
4MB Video Display Cache (Option).
•
1 VGA output port.
Additional Features:
•
Wake-on-LAN function.
•
Wake-on-Ring function.
•
Keyboard/Mouse/USB wake up function.
•
Supports S1, S3, S4 and S5 ACPI states.
Expansion Slots:
•
3 PCI slots.
