Lite-on Tech TR101 - Front Panel USB Connector Pinout; Front Side USB Connector Pin Definition

TR101 Motherboard
15
Jumper Introduction
cont.
The following table shows the Front Side USB Connector Pin Definition.
J19
Front Side USB Connector Pin Definition
Pin Signal Name Description
1 V2+ Front Side USB Port2 VCC
2 V1+ Front Side USB Port1 VCC
3 USB2+ Front Side USB Port2
Signal+
4 USB1+ Front Side USB Port1
Signal+
5 USB2- Front Side USB Port2
Signal-
6 USB1- Front Side USB Port1
Signal-
7 GND2 Front Side USB Port2 GND
8 GND1 Front Side USB Port1 GND
9 NC No Connect
10 USBOC USB Over-Current Detect
USB1+
V1+ V2+
USB2+
USB2- USB1-
GND2 GND1
NC USBOC
