Installing the Central Process Unit (CPU)
cont.
CPU Heat Sink Installation
1. Read the related CPU heat sink user’s manual for more detailed installation procedures.
2. Connect CPU fan power cable into the CPU fan connector on the motherboard.
CPU Fan Connector
