□  Motor No-Load Current Setting
Sets  the motor no-load current  when  running  at  no-load voltage and  rated frequency. This
information is not  written on the motor nameplate. Contact the motor manufacturer  for the
information.
□  Number of Motor Poles Setting
d2-03 is only enabled in Closed-Loop V/F Control and Closed-Loop Vector Control. Enter the
number of motor poles written on the motor nameplate.
□  Motor Line-To-Line Resistance Setting
d2-04  will  be  set  automatically  during  Auto-Tuning.  However  if  Auto-Tuning  cannot  be
performed, contact the motor manufacturer for the test report. Use the line-to-line resistance
listed in the rest report to calculate the line-to-line resistance by the following formula.
·  E-type insulation: the resistance value (Ω) listed on the test report at 75°C  ×  0.92
·  B-type insulation: the resistance value (Ω) listed on the test report at 75°C  ×  0.92
·  F-type insulation: the resistance value (Ω) listed on the test report at 115°C  ×  0.87
□  Motor Leakage Inductance Setting
d2-05 will be set automatically during Auto-Tuning.
□  Motor Rotor Resistance and Mutual Inductance Setting
6.6 Group E, Multi-Function Terminals

E1  Multi-Function Digital Inputs
  E1- 00 to E1- 05  Terminal S1 to S6 Function Selection
Assigns functions to multi-function terminals S1 to S6. Set this parameter according to Table
6.18.
Terminal S1 Function Selection
0 : 2-Wire Sequence Control (Forward/Stop)
Terminal S2 Function Selection
1: 2-Wire Sequence Control (Forward/Stop)
Terminal S3 Function Selection
Terminal S4 Function Selection
Terminal S5 Function Selection
Terminal S6 Function Selection
19: Baseblock Command (Normal Open.)
Table 6.18
