LiteOn EVO600043S2D2E20F Quick Start Guide

39
Parameter
Name
Description
Setting Range
3638: Resets 3-Wire Sequence / 60Hz / 380V
3641: Resets 3-Wire Sequence / 60Hz / 415V
3644: Resets 3-Wire Sequence / 60Hz / 440V
3646: Resets 3-Wire Sequence / 60Hz / 460V
A1-04
Password
Set password to parameter A1-05 and enter the
password to parameter A1-04 to unlock it.
Parameters A1-01 to A1-03, A1-06, A2-01 to
A2-15 cannot be edited until correct password
is entered to A1-04
Default∶ 0000
Min.: 0000
Max.: 9999
A1-05
Password Setting
A1-07
Pump mode enable
selection
Set whether the pump mode is ON
0: Standard mode
1: Pump mode (single pump)
Default: 0
Min.: 0
Max.: 1
Unit: -
A2: User-Defined Parameters
A2-00 to
A2-15
User-Defined
Parameters 1 to 16
Selects up to 16 parameters and assigns them
to parameter A2-00 to A2-15. Saved parameters
can be viewed in User-Defined Parameter
Access. To assign specific parameters to A2-00
to A2-15, set parameter A1-01 to 2. The saved
parameters A2-00 to A2-15 can only be viewed
if A1-01 is set to 1
Range: A1-00 to F1-12
A2-32
User-Defined
Parameter
Automatic Save
Saves the most recently edited parameters.
0: Do not save list of recently edited parameters
1: Save list of recently edited parameters
Default: 1
Range: 0, 1
Group b, Application
b1: Operation Mode Selection
b1-00
Frequency
Command
Selection 1
0∶ Keypad
1∶ Control Circuit Terminal (Analog Input)
2∶ Terminal Up/Down
3∶ Modbus Communication
Default∶ 0
Min.: 0
Max.: 3
b1-01
Run Command
Selection 1
0∶ Keypad
1∶ Control Circuit Terminal (Sequence Control
Input)
2∶ Modbus Communication
Default∶ 0
Range: 0, 1, 2
b1-02
Stopping Method
Selection
0∶ Ramp to Stop
1∶ Coast to Stop
2∶ DC Braking to Stop
3∶ Coast to Stop with Timer
Default∶ 0
Min.: 0
Max.: 3
