Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 286
Measurement Panel
Measurements, Features, and Settings
Measurement Illustration
X
Determines the X position of the opening's center.
Y
Determines the Y position of the opening's center.
Z
Determines the Z position of the opening's center.
Width
Determines the width of the opening.
Measurements
