Gocator Line Profile Sensors: User Manual
Gocator Device Files • 409
Element Type Description
ment
Measurements\Height Bounding Box tool
measurement
Height measurement.
Measurements\ZAngle Bounding Box tool
measurement
ZAngle measurement.
Measurements\GlobalX Bounding Box tool
measurement
Global X measurement.
Measurements\GlobalY Bounding Box tool
measurement
Global Y measurement.
Measurements\GlobalZAngle Bounding Box tool
measurement
Global Z Angle measurement.
Features\CenterPoint
GeometricFeature
CenterPoint PointFeature
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Bounding Box Tool Measurement
SurfaceCsHole
A SurfaceCsHoleelement defines settings for a surface countersunk hole tool and one or more of its
measurements.
