Gocator Line Profile Sensors: User Manual
Gocator Device Files • 375
Element Type Description
GapLength 64f Gap length (mm).
GapLength.min 64f Minimum gap length (mm).
GapLength.max 64f Maximum gap length (mm).
GapLength.used Bool Whether or not this field is used.
PaddingWidth 64f Padding width (mm).
PaddingWidth.min 64f Minimum padding width (mm).
PaddingWidth.max 64f Maximum padding width (mm).
PaddingWidth.used Bool Whether or not this field is used.
PaddingLength 64f Padding length (mm).
PaddingLength.min 64f Minimum padding length (mm).
PaddingLength.max 64f Maximum padding length (mm).
PaddingLength.used Bool Whether or not this field is used.
MinLength 64f Minimum length (mm).
MinLength.min 64f Minimum value of minimum length (mm).
MinLength.max 64f Maximum value of minimum length (mm).
MinLength.used Bool Whether or not this field is used.
MaxLength 64f Maximum length (mm).
MaxLength.min 64f Minimum value of maximum length (mm).
MaxLength.max 64f Maximum value of maximum length (mm).
MaxLength.used Bool Whether or not this field is used.
Threshold 64f Height threshold (mm).
Threshold.min 64f Minimum height threshold (mm).
Threshold.max 64f Maximum height threshold (mm).
ThresholdDirection 32u
Threshold direction:
0 – Above
1 – Below
FrameOfReference 32s
Part frame of reference:
0 – Sensor
1 – Scan
2 – Part
FrameOfReference.used Bool Whether or not this field is used.
FrameOfReference.value 32s Actual value.
IncludeSinglePointsEnabled Bool Enables preservation of single data points in Top+Bottom layout
IncludeSinglePointsEnabled.
used
Bool Whether or nto this field is available to be modified
EdgeFiltering Section
See EdgeFiltering on the next page.
