Function Settings [Factory settings] shown in brackets
Press s or t to change Press Q s or Q t to change
E.oP Event output [nonE] Function can be applied to each
segment independently to trigger
an output at the start of that
segment for the duration of that
segment. Setting blocked unless
either or both outputs SP2A or
SP3A have been configured as an
Event Output in Level 2 or Level A
respectively.
2d SP2A de-energised to mark event
2E SP2A energised to mark event
3d SP3A de-energised to mark event
3E SP3A energised to mark event
2d.3d SP2A and SP3A de-energised to
mark event
2E.3d SP2A energised SP3A de-energised
to mark event
2E.3E SP2A and SP3A energised to mark
event
2d.3E SP2A de-energised SP3A energised
to mark event
To Return to:
LEVL P Press and hold t
To Read % Programmer memory used:
USEd Press Q and t together in LEVL P / ProG 1
1-100%
3.7 Memory Allocation Table
Segment type Memory required
Ramp 4 Bytes
Ramp with Holdback 5 Bytes
Soak 2 Bytes
Step 3 Bytes
Loops (1-3) 1 Byte
Loops (4+) 2 Bytes
Call 1 Byte
Event Output 1 Byte
Program Header 1 Byte
Maximum capacity: 351 Bytes
31 Programs
126 Segments
Examples:
1. 1 program of 58 Ramps and 58 Soaks 349 Bytes
2. 4 programs of 14 Ramps and 14 Soaks 340 Bytes
3. 31 programs of 2 Ramps and 1 Soak 341 Bytes
4. 2 programs of 10 Ramps, 10 Soaks, 2 Steps and 1 loop 136 Bytes
3.8 Memory Full Indication
Should the programmer memory capacity be reached during program configuration, the
display will show ‘FULL’
