LNTECH S4 SERIES

6
Performance characteristics
Protective range
0～6000mm
Protective height H=(beams-1)×light axis pitch
Detection precision 14mm, 21mm,36mm
Light axis pitch 7.5mm,15mm,30mm
Light source Infrared light, 850nm
EAA
Max
2.5°
Resistance to light interference 10000Lux (angle of incidence >=5°)
Electrical properties
Operating power DC24V±15%
Power consumption <10W(without load)
Control output
Dual transistor output
（
PNP or NPN
）、
load current
100mA
，
residual voltage below 1.4V
Auxiliary output
Single transistor output （PNP）、
load current
120mA，
residual voltage below 1.4V
Response time
5～35ms
Status indicator
Emitter
light passing(green),light intercepting(red),LED indicator
light;state,fault indicator(LED display)
Receiver
light passing(green),light intercepting(red),LED indicator
light;state、fault indicator(LED display)
Noise immunity
IEC61000-4-4：level Ⅲ/IEC61000-4-2：level Ⅲ
Insulating resistance
＞100MΩ
Dielectric strength
AC1500V，60s
Physical characteristics
Ambient temperature
-10℃～55℃
Humidity
20℃,RH≤85%
Vibration
Frequency range: 10 to 55 Hz
Sweep rate: 1 octave/min
Amplitude: 0.35 ± 0.05 mm.
Number of sweeps: 20 for each of three mutually
perpendicular axes
Sealing IP65
Shell material
Sensor: Aluminium alloy;
Light lter: PMMA
Technical Parameters
2.5
The protector technical parameters sheet
