1 Introduction
e information contained in this manual provides general guidelines for the implementation of the CON·X·US remote
communication device with Lochinvar boilers.
Now from virtually anywhere you can:
• Monitor boiler plant operating conditions at unlimited locations
• Re-program SMART SYSTEM control parameters
• Setup custom text or e-mail alerts for contractor and building owners/managers
ETHERNET PORT
LED 0 - LED 5
WI-FI CARD
DISPLAY RIBBON
CABLE CONNECTION
POLARITY
LED
CONTROL RIBBON CABLE
CONNECTION
WLAN LED
QR CODE
Figure 1-1_CON·X·US Board Components
CON·X·US board layout
LED 0 - LED 5
LED Description
LED 0
N/A
LED 1
Control to Display Communication Error
LED 2
CON·X·US Communication
LED 3
N/A
LED 4
Control to Display Communication
LED 5
Power Confi rmation
