Technical data
Jack 3.5 mm: .........................................................Headphones 32- 2000 ohm
Mini-DIN (AVS) Video IN:..............................................................Y/C (S-VHS/Hi 8)
............................................................CVBS (VHS/8 mm)
Cinch (yellow) Video IN:...........................................................CVBS (VHS/8 mm)
Cinch (white/red) Audio IN: ............................................................L (white) / R (red)
2x IEC socket 75 Ohm/5 V/80 mA: ................................Antenna/cable/DVB-T/C
2x F socket 75 Ohm 13/18 V/350 mA: ..............................ANT-SAT DVB-S/S2
2 x
screw terminals
Speaker Right: .....................................................+ (red) / - (black)
2 x
screw terminals
Speaker Left: ........................................................+ (red) / - (black)
Jack 3.5 mm AUDIO IN2: ..............................................................................L/R
Cinch AUDIO IN max. 2Vrms:.......................................................Centre
2 x Cinch AUDIO IN1: ........................................................L (white) / R (red)
2 x Cinch AUDIO OUT (level depends on configuration): ...L (white) / R (red)
Cinch COMPONENT IN: .......................................................Cb/Pb signal
Cinch COMPONENT IN: .........................................................Cr/Pr signal
Cinch COMPONENT IN: .............................................................. Y signal
Cinch AUDIO DIGITAL IN (SPDIF): ........................................Digital audio
Cinch AUDIO DIGITAL OUT (SPDIF): ....................................Digital audio
SUB-D AUDIO LINK: .............................................................. Multi-sound
SUB-D PC IN:..............................................................PC/STB video signal
SUB-D RS-232C: ................................................................serial interface
Mini-DIN SERVICE: .................................................................. Service/L-Link
Mini-DIN CONTROL: .................................................Rotating stand control
2 x USB USB 2.0: .................................................. Standard JPEG/MP3 files
2 x HDMI Digital Video/Audio IN
Type A 19pole Standard 1.3: ....................Digital video and audio
2 x CI-Slot Common Interface .........................................Slot for CA module
Electrical data
Chassis designation: ........................................................................................... L 2710
Power supply: ........................................................................220 V – 240 V/50–60 Hz
Tuner: .................................................................................. VHF/UHF/cable/hyperband
Range:.......................................................................................... 45 MHz to 860 MHz
Station storage locations incl. AV and radio: .........................................................4000
TV standards: .................................................................................. B/G, I, L, D/K, M, N
Colour standard: ....................................... SECAM, PAL, NTSC, NTSC-V, PAL-V (60 Hz)
Sound standard .....................................................Mono/Stereo/2-Ton/Nicam B/G, I, L
......................................................Dolby Digital, Dolby Virtual Speaker, DTS
Audio nominal power (sine): ....................................................................... 2 x 20 watt
Teletext: .......................................................................................... TOP/FLOF Level 2.5
Page memory ........................................................................................................2000
Digital teletext (only in UK / IRL with active MHEG-5 software) .......................MHEG-5
Connections (max. equipment)
Mains socket: ..................................................................................... Supply voltage
EURO-AV 1 Video IN: ....................................................................Y/C (S-VHS/Hi 8)
.................................................................CVBS (VHS/8 mm)
Video OUT: .............................................................CVBS (VHS/8 mm)
................................................................Y/C (S-VHS/Hi 8)
Audio IN: ........................................................................................L/R
Audio OUT: .....................................................................................L/R
EURO-AV 2 Video IN: ....................................................................Y/C (S-VHS/Hi 8)
.................................................................CVBS (VHS/8 mm)
.......................................................................................RGB
Video OUT: .............................................................CVBS (VHS/8 mm)
......................................... Y/C, (only with SVHS Link Plus)
Audio IN: ........................................................................................L/R
Audio OUT: .....................................................................................L/R
General data
Type Individual 40 Compose Full-HD
+
100 Individual 46 Compose Full-HD
+
100 Individual 52 Compose Full-HD
+
100
Article number 67437xxx 67439xxx 67440xxx
Device dimensions without base (W x H x D) in cm 101.4 x 61.7 x 10.3 114.1 x 69.2 x 11.4 130.8 x 78.5 x 12.8
Weight (approximate) in kg 31.5 35.7 52.0
Display FHD-LCD technology FHD-LCD technology FHD-LCD technology
Picture diagonal in cm/picture format 101 / 16:9 117 / 16:9 132 / 16:9
Resolution in pixels 1920 x 1080 1920 x 1080 1920 x 1080
Dynamic contrast ratio 10,000:1 10,000:1 10,000:1
Static contrast ratio 2,000:1 2,000:1 2,000:1
Viewing angle horizontal and vertical 178° 178° 178°
Power consumption (EN 62087)
in operation (watt)
in standby (watt)
145
1,2
165
1,8
180
1,8
Ambient temperature (Celsius) 5° – 35°
Relative humidity (non-condensing) 20 – 80%
Air pressure 800 – 1114 hPa (0 – 2000 m above sea level)
