Loewe Concept L 32 Basic User Manual

17
L2650
Art.-Nr. Art. No. 65433.Y60 65433.Y50 65421.Y27 65421.Y87 65421.Y17 65421.Y77 65434.Y60 65434.Y50 65422.P27 65422. A/P/T89 65442. Y/D(T)27 65442. Y/D(T)89 65442. T/W17 65442. T/W79
Geräte-Typ
TV set type Concept L26 BASIC Concept L26 BASIC Concept L26 DVB-T CI Concept L26 DVB-T/C CI Concept L26 DVB-T CI Concept L26 DVB-T/C CI Concept L32 BASIC Concept L32 BASIC Concept L32 DVB-T CI Concept L32 DVB-T/C Concept
L32DVB-T CI
Concept L32DVB-T/C Concept
L32DVB-T CI
Concept L32DVB-T/C
Baugruppen • Components
Signal Board
89445
060 x
061 x
062 x
064 x
067 x
362 x x
364 x x
367 x x
460 x
461 x
464 x
Basic Board
89435
050 x x x x x
350 x x x x x x x x x
Buchsenplatte
Connector Board
89194 051 x x x x x x x x x x x x x x
Bedienteil+IR
Control Unit+IR
89407 050 x x x x x x x x x x x x x x
LCD Display 26”
Sharp GA7L
(89446)
90433
(001)
966
x x x
LCD Control Unit 90433 971 x x x
Inverter Unit 90433 973 x x x
Inverter GND Unit 90433 974 x x x
Microprocessor Unit 90433 972 x x x
LCD Display 26“
Sharp ASV 2.3
89683 001 x x x
LCD Display 32“
Samsung L03
32575 x x x
LCD Display 32“
Samsung L14
89571 001 x x x
LCD Display 32”
Sharp GA7L
(89438)
90433
(001)
932
x x
Inverter-A Unit
90433 962 x x
Inverter-B Unit 90433 963 x x
Inverter GND Unit 90433 964 x x
LCD Control Unit 90433 960 x x
Microprocessor Unit 90433 961 x x
Tuner 04
89222 063 x x x x
Tuner H04
89222 064 x x x x x x x x x x
Fernbedienung RC4
Remote Control
89800 A01 x x x x x x x x x x x x
Fernbedienung RC5
Remote Control
89665 A00 x x
CI onboard 89346 050 x x x x
NRS • Retrofit Kit
DVB-S
enthält/contains
89189.056
89361 056 x x x x x
CI ext. 89346
080
(=050)
x x x x x x
PiP T/C
89442
080
(=050)
x x x
Baugruppenübersicht • Components chart • Correspondances des modules • Ordinamento dei gruppi
Vista general de módulos • Overzicht van de modules
