Page #12 background imageLoading...
Page #12 background image
Levelling the Washing Machine
There are 4 levelling feet on the underside. They must be adjusted to make sure the washing
machine is level.
1. On each stand, loosen the lock nut by turning it clockwise with a
spanner.
2. Adjust all four feet in this way.
3. Use a spirit level to ensure the washing machine is level.
4. Tighten each lock nut by turning them anti-clockwise (towards
the washing machine body), again using a spanner.
Ensure all four lock nuts are tightened securely. Check the feet are still
bolted to the washing machine - if they’re unbolted, the washing machine
will move around.
Water Supply Hose
Points to remember
Follow the instructions in this section to avoid water leaks.
Don’t connect the hose to a combination tap.
Don’t twist, squash, modify or cut the hose.
Optimum water pressure in the main pipe is 0.03 MPa - 1.0 MPa. If the water pressure is
set higher than this, you will need to install a depressurising valve. Water-flow from the
tap should be more than 5 litres per minute. If youre unsure, ask a qualified technician to
connect the hose.
This unit must only be connected to the cold water mains using the new water inlet hose
provided.
Connecting the Water Supply Hose
1. Attach the hose to a tap, and tighten
the plastic joint by hand.
2. Open the tap slowly and check that
there are no leaks around the joint.
Lock nut
3/4”
min. 10 mm
3/4”
min. 10 mm
Plastic joint
The joint is subject to water
pressure.
INSTALLATION
12
