7
Main Unit
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to local
regulations.
The following items are included:
Pan Support (Left/Middle/Right) × 3 Grill Pan Handle set x 1
100 mm Burner Ring × 1
100 mm Burner Cap × 1
Stability Bracket × 1 Stability Bracket Screws × 2
Stability Bracket Wall Plugs × 2
Shelf × 2
Baking Pan Shelf × 1
Splash Back × 1 Splash Back Screws × 2
75 mm Burner Ring × 2
75 mm Burner Cap × 2
55 mm Burner Ring × 1 Multi Ring Burner Ring × 1
55 mm Burner Cap × 1 60 mm & 130 mm Multi
Ring Burner Cap × 1
Thank you on the purchase of your new Logik Dual Fuel Range Cooker.
You must read this manual in order to fully understand how to operate it correctly.
This unit MUST be installed by a competent and registered engineer (Gas Safe in the UK).
Please allow the installer to view the installation section of this manual.
Read all the safety warnings carefully before use and keep this manual for future reference.
If items are missing or damaged please contact Partmaster (UK only).
Tel: 0344 800 3456 for assistance.
* All images are for indication only; please refer to your individual unit for actual item.
LPG Replacement Rating
Plate Sticker × 1
LPG Conversion Kit:
LPG Nozzle × 5
Type of gas
3+ G30/31 28-30/37 mbar
LFTG90W14_IB.indd 7 09/02/2015 17:51
