Logik LFTG90W14 User Manual

8
Product Overview
The Hob
Control Panel
1. Standard Burner (75 mm)
2. Large Burner (100 mm)
3. Small Burner (55 mm)
4. Multi Ring Burner (middle 60mm, outer 130mm)
1. Oven Timer Control
2. Oven Functions Control
3. Oven Temperature Control
4. Front Left Hob Control
5. Back Left Hob Control
6. Multi Ring Hob Control
7. Back Right Hob Control
8. Front Right Hob Control
2 3 4 5 6 7 81
1
3
4
2
* All images are for indication only; please refer to your individual unit for actual item.
1
LFTG90W14_IB.indd 8 09/02/2015 17:51
