Logik MP3-128 LCD User Manual

Installing the MP3 Player
Installation of drivers for computers using Windows Me/2000/XP is not necessary.
Note for Windows Me/2000/XP users: Installation of the MP3 Player drivers is required only if you
wish to upgrade the firmware of the player.
Note for Windows 2000 users: Windows Service Pack 3 must be installed before installing MP3
Player drivers.
Windows 98 SE users will need to install the MP3 Player on their system:
Insert the CD-ROM and the menu will appear.
1. Click the Setup Driver Button to begin the installation.
2. Follow the screen instructions to complete the installation
Or
1. Click the View Manual Button to browse the manual.
2. In the manual, click on the link below to open the folder containing the MP3 Player
installation program.
3. Click on the Setup icon to begin the installation.
4. Follow the screen instructions to complete the installation.
Transfer data to and from the MP3 Player.
1. Make sure that the MP3 Player is turned off.
2. Remove the USB port cover & disconnect the
earphone.
3. Plug the MP3 Player into the USB port of your
computer. The built-in LCD displays "READY",
indicating that the MP3 Player is in USB mode. The
MP3 Player is then automatically recognized (in 'My
Computer') as a removable media device.
4. Transfer files to or from the internal Flash RAM using
Windows explorer.
5. Unplug the MP3 Player from your computer,
WMA/MP3 files can now be listened to and all data
stored can be transferred to another computer.

Logik MP3-128 LCD Specifications

System Memory

internal memory	128MB, 256 MB, 512 MB or 1 GB

Power

battery type	1 x AAA Battery
battery continuous playing time	Up to 8 hours

Display

display resolution	128 x 32 dots
display type	Dot-matrix LCD with backlight

Processor

processor speed	75 MIPS DSP

Audio

signal to noise ratio	> 90 dB
frequency response	20 Hz ~ 20 kHz
output power	< 11 mW (each output)
