1. Insert the round end of the stand
into the receptacle.
2. Slide the stand to the direction as
shown until it is locked tightly in
position.
N o t e: T he p hot o fr am e c an b e
placed vertically or horizontally for
both landscape and portrait display.
Attaching the stand
Preparations
Landscape viewing Portrait viewing
Connecting to the power
1. Connect the supplied AC power
adaptor (5V, 1.5A) to the DC in
jack and then plug the other end to
the wall outlet.
Changing the Frame
1. Pull up the frame along its edge
from the unit using your ngers.
Note: Make sure all the clips
around the frame are entirely
unlocked before pulling away
from the unit.
2. Hold the other supplied frame
with the Arrow ( ) marking
pointing upright, and then place it
on the unit in an upright position.
3. Press the frame around the edge
until it sits in place. Now the frame
is changed successfully.
