Logitek mixIT Audio Console System/JET67 Manual
36
+
-
Gnd
+
-
Ana
Out 11
Ana
Out 12
mix-IT-12 only
+
-
Gnd
+
-
Ana
Out 13
Ana
Out 14
mixIT-12 only
+
-
Gnd
+
-
Ana
Out 15
Ana
Out 16
mix-IT-12 only
GPIO
DB-15 Connector (female jack mounted on chassis)
1. Out-1 9. +3.3 VDC
2. Out-2 10. Out-7
3. Out-3 11. In-1
4. Out-4 12. In-2
5. Out-5 13. In-3
6. Out-6 14. In-4
7. Out-Common 15. Out-8
8. Ground
Inputs grounded to activate. The maximum input is 12 volts. The outputs are opto-isolated
electronic relays. The maximum load is .5 amps at 50 volts.
