Logosol Multifunctional Servo Drive LS-231SE
Doc # 712231004 / Rev. A, 05/05/2011
Logosol, Inc. • 1155 Tasman Drive • Sunnyvale, CA 94089 Tel: (408) 744-0974 • www.logosolinc.com
7
DUAL-LOOP MASTER ENCODER INTEFRACE
LS-231SE1 is master encoder interface for dual-loop applications with LS-231SE Multifunctional Servo
Drive.
DUAL-LOOP MASTER ENCDOER INTERFACE DIMENSIONAL DRAWING
DUAL-LOOP MASTER ENCODER INTERFACE LAYOUT
