ENGINE PARAMETER
- 19 -
10. Battery（optional）
Please choose the battery, 12V, rated capacity of 20Ah. or more。
Never connect the positive and
negative electrodes in reverse, otherwise, it will
damage the engine and battery severely.
Check the electrolyte level in cell if they are in the
position between the top limit line and low limit
line. If the electrolyte level is lower the low limit
line, screw out the cap and fill distilled water till it
rises up to top limit line. All electrolyte level in
cells should be almost in the same height.
· If operate improperly, the battery may explode，thus, hurt may occur to the persons
around, therefore, keep the smoke and flame and inflammable things away from the
battery.
· the battery will release explosion gas, keep the fire away from it. When charge the
battery or use the battery, keep ventilating.
Connect start motor：
Be careful not to connect the terminals in reverse, or short circuit occurs. As usual,
connect the positive electrode before do it for negative one.
1) Connect positive wire of the battery to the terminal of start relay.
2) Connect negative wire of the battery to the screw of engine bracket.
3) Connect positive wire of the battery to the positive terminal of the battery.
4) Connect negative wire of the battery to the negative terminal of the battery..
Upper line
Lower line
Caution
Warning
