LONCIN LC2V78 User Manual

ENGINE PARAMETER
- 20 -
11. Engine parameters
Engine Type
2-cyl、4-stroke、forced air cooling、OHV
Displacement
（bore X stroke）
678ml（78X71mm）
Max power
(kW/3600rpm)
14.7
Max torsion(N·m)
speed(rpm)
43.5/2500
Fuel rate
(g/kW·h)
≤360
Idle speed
(rpm)
1500±150
Speed fluctuation ratio ≤10%
Compression ratio 8.5:1
Start mode Powered start
Rotation direction
CCW（face to output side）
Inlet 0.10~0.15
Valve gap (mm)
outlet 0.15~0.20
Spark plug F7TC
Plug clearance (mm) 0.7~0.8
Ignition mode Thyristor no-contact ignition
Type of air cleaner Double elements
Dimension (mm)
L×W×H
455X400X450
Net weight (kg) 45
