33
Auxiliary DC jack
The auxiliary DC jack is located at the right side
of the front panel. The auxiliary DC jack can be
used for suitable work lights, radios, etc. The
auxiliary DC jack should only be used when the
engine is running and the headlights are turned
off.
1. Auxiliary DC jack cap
1. Set the light switch to “OFF”.
2. Turn the accessory off.
3. Start the engine. (See Chapter 6.)
4. Open the auxiliary DC jack cap and then
insert the accessory power plug into the
jack.
1. Auxiliary DC jack
5. Turn the accessory on.
6. When the auxiliary DC jack is not being
used, cover it with the cap.
Maximum rated capacity for the auxiliary
DC jack:
DC 12V,10A(120W)
