Long range MT4300 - Link Mode Confirmation; Confirming and Retrying Link

6
8
Press ENTER Twice
With the desired trap and channel entered on
the MT4300 press nter twice.
Retry if Necessary
If link is unsuccessful, the message No Link
Response is displayed on the screen. Press
1 to retry.
1
2
Link Mode
Select Trap/ Chn
Tr ap
Chn
Enter to Link
1)
No Link
Response
Retry
Back to Quit
Conrm Link
If link is successful the message Receiver
Linked will display on the screen. Press 1 to
link the next trap.
Repeat for the Remaining Traps
When done, press BAC to return to the Set
RF Channel Menu.
If you miss the 15 second window to perform
the link function, the Link LED on the R4300
receiver stays ON. Turn the machine OFF
or remove power from the receiver, wait 5
seconds and reconnect power. Repeat steps
to link.
1)
Receiver
Linked
Next
Back to Quit
1
2
Set RF Channel
MT Channel
Link Mode
7
9
Complete the remaining steps on the MT4300 while the R4300 receiver is in link mode.
