MigWeld™ 100 - 100 AMP MIG Welder
120v
Page 1 of 8
Specifications
Rated AC Output Amps Duty Cycle Volts
Max setting 80 20% 22.5 Max OCV
30V
Min setting 60 20% 20.5
Rated AC Input 120VAC, 60Hz,18Amps(For use on a 20Amps branch circuit)
Ground Cable 6AWG, single insulation, 6 foot
Torch Power cable 6AWG, single insulation, 6 foot
Power Cord 3-core, double insulated, 14AWG
Thermal Overload Both settings: 6min.shutdown, 10min.back on with light
Welder Tip 0.030” and 0.040”
Wire Size 0.030” –0.040” flux core wire
Wire Spool Size 4”diameter
Overall Dimensions 37×21×31cm
Weight 15.6kgs
Accessories
0.040” welder tip, Welding Face Shield,
Wire Brush/ Hammer Combination
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instructions, operating
and maintenance procedures, parts list and diagram. Keep your invoice with this manual. Write the invoice
number on the inside of the front cover. Keep the manual and invoice in a safe and dry place for future
reference.
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool！
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in damp or wet locations. Don’t
expose to rain. Keep work area well-lighted .Do not use electrically powered tools in the presence of
flammable gases or liquids.
3. Keep children away. Children must never be allowed in the work area. Don not let them handle
machines, tools or extension cords.
4. Store idle equipment. When not in use, tools must be stored in a dry location to inhibit rust. Always
lock up tools and keep out of reach of children.
5. Do not force tool. It will do the job better and more safely at the rate for which it was intended. Do not
use inappropriate attachments in an attempt to exceed the tool capacity.
6. Use the right tool for the job. Do not attempt to force a small tool or attachment to do the work of a
larger industrial tool. There are certain applications for which this tool was designed. Do not modify
this tool and do not use this tool for a purpose for which it was not intended.
7. Dress properly. Do not wear loose clothing or jewelry as they can be caught in moving parts. Protective,
