MigWeld™ 100 - 100 AMP MIG Welder 120v
Page 4 of 8
Unpacking
When unpacking, check to make sure the following parts are included.
Assembly
1. Attach the handle (30) to the cover (31) using screw (29) insert from the handle top-rear. Refer to the
photo at the top of page 6, and the Assembly Drawing on page11.
2. Attach the cover Locking Spring (8) to the front of the Base Frame (14) using the supplied self-tapping
screw.
MIGWELD 100 Welder
Power Cord (32)
Ground Cable (33)
Torch (1)
Face Shield (38)
Cover Locking Spring (8)
Wire Reel (27)
Wire Brush/Hammer (39)
Cover (31)
