Machine Conguration
The hardware conguration is saved internally inside the machine. When switching on, the MAPRO is reading the
conguration and compares it with the actual present hardware identications of the DRV, the actual software ver-
sion and the identication of the front panel.
If the conguration does not match the actual hardware conguration or if the conguration could not be read cor-
rectly, the machines stops with E30 “Conguration”.
code designation cause
E30-04 conguration primary the measured bus voltages do not match the actual saved conguration
E30-05 error conguration error when reading the conguration: no valid data present or data is corrupted
E30-06 conguration software the actual software does not t to the hardware
R25 R26 R27 conguration DIP1 DIP2 conguration
X X 300 / 350 OFF OFF 3-phase 400V
X 400 OFF ON 3-phase 230V
X X 500 ON OFF multivolt (selection switch 230V / 400V)
Conguration resistors DRV13 DRV15
R25
R26
R27
DIP
DIP
R25
R26
R27
Conguration resistors DRV17
R25
R26
R27
DIP
