8
Pairing Cameras
6. Pairing Cameras
To pair the cameras to the receiver:
1 Make sure that the cameras and receiver are both powered up and all antennas are properly
attached.
2 Press the Pair button on the receiver to toggle between channels. Use CAM1 when pairing the
first camera and CAM2 for the second.
3 On the receiver, press and hold the Pair button for 5 seconds to activate pairing mode.
4 On the back of the camera, press the Pair button. This must be done within 30 seconds of
pressing the Pair button on the receiver.
• If pairing is successful, live video from the camera will appear on the monitor.
IMPORTANT
The cameras and the receiver have already been paired out of the box, which
means that they are exclusively communicating with each other. If for some
reason the pairing is lost, follow these steps to pair the cameras and receiver.
Pair button
Channel Indicator LED’s
