Lorex LW2232 User Manual

2
Wireless Receiver
2. Wireless Receiver
1 Removable Antennas (SMA Type): Pre-attached to the receiver.
2 Channel Indicator LEDs: Glow green to indicate which channel is selected for pairing.
3 Pairing Button: For details, see
“Pairing Cameras” on page 8.
4 DC Power: Connect power adapter
to power on the receiver.
5 Termination Cable: Includes 2 BNC
video output cables to connect
cameras to a DVR.
6 Antenna Jacks: One on each side of
the receiver.
1
2
3
5
4
6
