Lorex LW2232 User Manual

3
Wireless Camera
3. Wireless Camera
1 Removable Antenna (SMA Type): Pre-attached to the back of camera.
2 Camera Stand
3 DC Power: Connect power adapter to power on the camera.
4 Pairing Button: For details, see “Pairing Cameras” on page 8.
5 Antenna Jack
1 2
4 5
3
ATTENTION - This camera includes an Auto Mechanical IR Cut Filter. When the camera
changes between Day/Night viewing modes, an audible clicking noise may be heard
from the camera. This clicking is normal and indicates that the camera filter is working.

Lorex LW2232 Specifications

General

Brand	Lorex
Model	LW2232
Category	Security Camera
Language	English
