Wireless Receiver

Removable Wireless Antenna (SMA):

Connects to antenna jack on the

back of the receiver.

1. VGA mode has a resolution of 640 X 480 pixels; QVGA

mode has a resolution of 320 X 240 pixels. Use VGA mode

for best video performance. Use QVGA mode for a higher

video frame rate.

3 4

Front LED:

Glows green to indicate the

receiver is powered on.

Pairing button:

For details, see See “Pairing

Cameras” on page 11.

Termination cable:

Contains power, RCA video,

and RCA audio connectors.

Antenna jack:

Connection point for the

wireless antenna.

Resolution button:

Press to switch between VGA

and QVGA resolution
