4
Wireless Camera
2
1
6
5
4
Removable Wireless Antenna (SMA):
Connects to antenna jack on the back of the
camera.
Camera stand
Pairing button:
For details, See “Pairing Cameras” on page
11.
AC Power Cable
Antenna jack:
Connection point for
the wireless antenna.
1
6
6
4
5
2
ATTENTION: This camera includes an Auto Mechanical
IR Cut Filter. When the camera changes between Day/
Night viewing modes, an audible clicking noise may
be heard from the camera. This clicking is normal and
indicates that the camera filter is working.
3
Microphone
3
To Next Page
