Lortone 45C - Parts Lists; Parts for 33 B & 3-1.5 B Models

7
PARTS LIST 33B, 3-1.5B
Part No. Description
A 004-104 Frame
B 489-094 Offset Nylon Washer
C 004-005 Motor Cover, Top
D 004-006 Motor Cover, Bottom
E 004-007 Drive Shaft
F 004-008 Idler Shaft
G 001-100 Motor Pulley w/fan
H 004-102 Drive Pulley Assy
I 203-010 Bearings
J 206-012 Retaining Rings
K 210-002 Belt
L 301-034 Motor (110v)
L 301-035 Motor (230v)
M 350-005 Cord
N 320-001 Strain Relief
O 486-021 Screw
P 489-093 Nylon Washer
Q 481-011 Cap Nut
R 209-003 Foot
Part No. Description
020-091 Complete Rubber Barrel Assembly,
3 lb Capacity (for 33B)
020-090 Complete Rubber Barrel Assembly,
1.5 lb Capacity (for 3-1.5B)
S 020-100 Inner Lid w/Bolt, 3 Lb & 1.5 Lb.
T 020-001 Outer Lid, 3 Lb & 1.5 Lb.
U 481-070 Knurled Nut
V 240-010 Boot Gasket, 3 Lb & 1.5 Lb.
W 240-002 Rubber Barrel Only, 3 Lb.
W 240-001 Rubber Barrel Only, 1.5 Lb.
X 108-001 Barrel Washer
