Dimensional drawings| Installation Manual
Dimensional drawings
Sonar module
72.9 mm
(2.86”)
219.3 mm
(8.63”)
197.3 mm
(7.76”)
175.1 mm
(6.89”)
115.48 mm
(4.54”)
192.1 mm
(7.56”)
5
