Sonar Page
Displays the water column moving from right to
left on your unit’s screen.
Fish arches
Surface Clutter
Range scale
Colorline
Pages
Downscan page
The Downscan page shows the water column
moving from right to left. You can overlay downscan
sonar on the conventional sonar page by selecting
Dowscan Overlay on the Sonar settings menu.
Structure
Fish
Surface clutter
Range scale
