16
Com-1 wiring to transmit NMEA position information
to another NMEA-compatible device.
GlobalMap 3600 iGPS Cable Connections.
Mounting the Unit: Bracket or Portable
You can install the GlobalMap 3600C on the top of a dash with the sup-
plied gimbal bracket. It can also be mounted on a portable power supply.
If you use the supplied bracket, you may be interested in the optional
R-A-M
bracket mounting system. This converts the unit's gimbal
Ground
To Other
Device
Com-1
To GlobalMap
3600C
To Next Page
