LPKF S64 - Assembly Dispenser; Step 1: Dispenser Unit Preparation and Mounting

Upgrade dispenser S64/ S104
Assembly dispenser
11/15
LPKF Laser & Electronics AG | 05.10.2021 | V 1.0
4 Assembly dispenser
Step 1
 Remove the cover sheets from the old
dispenser unit using a Torx screwdriver
T8
 Mount the cover sheets on the new
dispenser unit using a Torx screwdriver
T8
 Mount the dispenser
 Fasten the three screws using a Torx
screwdriver T10
