(4) Hydraulic System Diagram

Mechanical type

1. Hydraulic oil filter

2. Steering pump

3. Steering unit

6. Hydraulic lift pump

7. Front outlet valve

8. Remote control valve

11. Hydraulic lift cylinder

12. Safety valve

13. Oil tank (Transmission)

3 3

3 - 19

3. Steering unit

4. Steering cylinder

5. Independent PTO valve

8. Remote control valve

(optional)

9. Hydraulic lift control valve

10. Down speed control valve

13. Oil tank (Transmission)
