LS tractor G3033 - How to Drive and How to Stop

1. Pull the position control lever
back to lift the implement up after
starting engine.
2. Set the engine speed at 1500
rpm.
4-2. How to drive and how to stop
(1) How to drive
Mechanical type
Position control lever
rpm.
3. Depress the clutch pedal fully.
4. Place each transmission gear
lever (Main, Range, Shuttle lever)
on the desired position.
5. Press the brake pedal and
Down speed
control knob
Clutch pedal
Brake pedal
Throttle pedal
Differential
lock pedal
Shuttle lever
Throttle lever
4
4 4
4 - 4
5. Press the brake pedal and
release the parking brake lever.
6. Release the clutch pedal slowly,
and the tractor starts.
▶ Release the clutch pedal slowly. If you release the clutch pedal suddenly, the gear
life shall be reduced and it might start suddenly.
Notice
4WD lever
Main gear
shift lever
Range gear
shift lever
