(2) Checking Transmission oil
Stop the tractor on level surface and apply the
Parking brake and lower implements to the
ground.
Clean around oil filling inlet and pull the gauge
straight out.
If oil level is between low and high mark of oil
gauge, it means proper amount.
For oil specification, refer to the section,
Lubricants and Capacity, at the end of this
manual.
(or, See page 5-5)
The contaminated oil may reduce the durability of transmission and cause the
<Oil gauge >
High
Low
Oil filling inlet,
Oil gauge
(3) Checking Front axle oil
Unscrew the oil gauge and check if the oil level is
between low and high marks.
If necessary, add new oil into the oil filling inlet.
(after 5~10 minutes later, check the oil level again)
For oil specification, refer to the section, Lubricants
and Capacity, at the end of this manual.
(or, See page 5-5)
Oil filling inlet & Oil gauge
The contaminated oil may reduce the durability of transmission and cause the
failure of hydraulic system. Clean around oil filling inlet and then open the cap.
Caution
(4) Battery check
Refer to the section, Batter handling and Notices. (See page 5-29 )
5
5 5
5 - 17
(5) Air cleaner (Dry type)
(See page 5-11)
(6) Cleaning of Radiator and Radiator screen
(See page 5-12)
