Main fuse is attached to the wiring of right side of
the engine.
If main fuse is damaged, remove it from the
wiring and replace with a genuine part.
As main fuse is a device to protect the electric
system and wiring, if damaged, check if there is
trouble in the electric system. Contact your
authorized dealer for check.
②
②②
② Main fuse (SLOW BLOW FUSE) check and replacement
Main fuse
Capacity:50A
▶
If main fuse is cut off often, contact your authorized dealer to check the problem.
▶
If using the alternatives instead of the rated capacity main fuse, it may cause the
fire which results in the damage of tractor or injury.
▶
Do not connect electric wire to the battery terminals directly. It may cause a fire by
spark.
Notice
5
5 5
5 - 28
