 This indicator will be ON when pressing brake
pedal.
10
Parking brake indicator
 This indicator will be turned on when turning the
key switch to “ON” position, and will be turned
off after starting engine.
 If this bulb becomes lit during operation, it
indicates that the charging system is not
operating normally. Contact your authorized
local dealer for checking the electrical charging
system.
9
Battery charging indicator
 This gauge indicates the remaining amount of
fuel. If the needle indicates “E”, fill the fuel tank
immediately.
 The gauge activates when the key switch is in
the ON position. It will register "empty" with the
key switch in the OFF position.
8
Fuel level gauge
 The light indicates oil pressure only and goes
out when sufficient oil pressure is present at the
oil sender.
 This indicator will be turned on when turning the
key switch to “ON” position, and it will be turned
off after starting engine.
 If this indicator is turned on during operation,
stop the engine immediately and contact your
authorized local dealer for checking the engine
lubrication system.
12
Engine oil pressure indicator
11
Brake pedals not latched indicator (Not used)
10
11
12
 This indicator is not used in this model.
