PART ILLUSTRATIONS
GENERAL INFORMATION
Illustrations
Directional Reference
Part Order
Instructions
▶ GROUP NAME
: Detail classification name for parts.
▶ SECTION NAME
:Classification name for parts.
▶ COMPONENTS
: The components of an assembly are identified by a bracket.
▶ NO.
: Reference numbers are assigned to parts in the figure.
INTERCHANGEABILITY
: Indicates the interchangeability of parts due to design change
indicates that either parts can not be used.
~4265-99999
5265-00001~
indicates that a part has a serial number break.
When you order this part, please order a part according to the serial
number of the Loader.
★ Due to our policy of continuously improving products, The information contained herein is
subject to change without notice
The individual parts in their normal relationship to each other. Referencenumbersareusedinthe
illustrations. These numbers correspond to those in the "Number" column and are followed by
the quantity required and description.
Orders must give the complete description, correct part number, the total amount required, the
product model, all the necessary serial numbers, the method of shipment and the shipping
address.
"Right hand" and "left hand" sides are determined by standing at the rear of the unit and facing
in the direction of forward travel.
Indicates that a new part can be used instead of an old part when you
order this part, please order new part.
indicates that either parts can be used.
- 19 -
