3 -9
a
25
Fuel filter warning indicator
When there is excess water in the fuel filter, this
indicator will be turned on. If this indicator is
turned on, remove the water in the fuel filter.
(See chapter 5-5-(1) in this manual.)
24
Vehicle control error warning indicator
If there is any of significant errors on the engine
or vehicle control, this indicator will be turned on
and blink with the diagnosis error codes on the
LCD panel (a).
At this time, after escaping from the emergency
area, contact your authorized local dealer for
check.
It determined by the position of the needle on the
tachometer. The tachometer is marked to
indicate 540 RPM of rear PTO.
If the tachometer registers above the 540 RPM
mark for rear PTO operation, this indicates a
dangerous over-speed condition. Reduce the
engine speed immediately.
26
PTO speed indicator
25 24
26
