3 -8
19
20
21
19
Fuel level gauge
 This gauge shows the fuel level in the fuel tank.
If the needle indicates “E”, fill the fuel tank
immediately with fuel.
 The gauge activates when the key switch is in
the ON position. It will register “empty” with the
key switch in the OFF position.
20
Engine oil pressure indicator
 The light indicates oil pressure only and goes out when sufficient oil pressure is present at the oil
sender.
 This indicator will be turned on when turning the key switch to “ON” position and it will be turned off
after starting engine.
 If the indicator is turned on during operation, stop the engine immediately and check the engine oil
level. If the engine oil level is normal, contact your authorized local dealer for checking the engine
lubrication system.
21
Battery charging warning indicator
 This indicator will be turned on when turning the key switch to “ON” position and it will be turned off
after the engine starts.
 If this bulb becomes lit during operation, it indicates that the charging system is not operating
normally. As the battery can be fully discharged under these conditions, contact your authorized
local dealer for checking the electrical charging system.
23
ESC mode indicator
 This indicator is turned on when operating the
ESC main switch to “ON” position and the ESC
mode is ready.
22
Low fuel level warning indicator
 When the fuel level in the fuel tank is below
minimum level, this indicator will be turned on. If
this indicator turns on, fill the fuel tank
immediately with fuel.
 When working on the uphill/downhill, the fuel
can be exhausted before this indicator is turned
on. Add fuel in advance.
22
23
